Specification
itemvalue
MCU:STM32F405
IMU(Gyro):BMI270
USB Port Type:Type-C
Barometer:Built-in
OsD Chip:AT7456E chip
BLE Bluetooth:Supported.Used for Flight Controller configuration
DJl Air Unit Connection Way:Two ways supported: 6-pin connector or direct soldering.
BetaFlight Camera Control Pad:Yes(CC pad on the front side)
ESC Telemetry UART:R4(UART4)
Mounting:30.5 x 30.5mm( 4mm hole diameter)
Dimension:41.6(L)x 39.4(W) x 7.8(H)mm
Weight:9.6g
Applicable model:Universal
